Vehicles

Vehicles Motion Solutions

Allied Motion’s products and systems are in use around the world in a very wide range of vehicle-related applications such as AGV traction, ATV and automotive steering, on- and off-highway equipment HVAC, patient and handicapped transport, military tracking and fire control, and agriculture and turf equipment subsystems to name just a few.

Deere_407506windrower

Agriculture Equipment Auxiliary Systems

Agriculture equipment like the windrower shown here are becoming increasingly electrified with the incorporation of brush and brushless electric motor-powered accessories.

PropPlane

Aircraft Emergency Fuel Boost Pump

Many small propeller-driven aircraft benefit from a two-speed pump that maintains fuel pressure while cruising, but boosts fuel delivery for takeoff and landing.

ActionTrackChair2

All Terrain Tracked Wheelchair

The Trackchair™ is a unique zero-turn-radius, all-terrain wheelchair developed to enable wheelchair-bound people, including veterans, to enjoy the freedom of getting off-road.

Polaris RZR ATV image

ATV Power Steering Assist Actuator

Electronic Power-Assisted Steering (EPAS) is found today in many off-road sports and utility ATVs as well as their on-road counterparts.

LNG-fill-up

Liquid Petroleum Gas Pump

As environmental concerns rise and the use of alternative fuels is encouraged, Liquid Petroleum Gas (LPG) systems are increasingly being deployed in taxis, transit buses, and similar vehicle fleets.

DARPA_Challenge_CMU_D2X_0840

Autonomous Vehicle Laser Sensor

DARPA’s annual “Urban Challenge” vehicle race spurs autonomous vehicle technology development. The implications for auto-drive cars and unmanned military operational vehicles are clear.

Airplane_Tail_iStock_000002385791Small

Auxiliary Unit Fuel Pump

In the control of gas turbine engines used in aircraft auxiliary power units (APU) that must operate at tens-of-thousands of rpm, fuel pump frequency response and reliability are two key design parameters.

Seakeeper_7000_Gyro4

Boat Gyro Stabilization System

Vessel roll caused by rough seas is an experience that can take the fun out of boating. With a dynamic gyro stabilization system on board, however, skippers and passengers can focus on pleasant pursuits on the water.

diesel_exhaust2

CO2 & NOx Emission Reduction Pump

Strict emission regulations like Euro 6 and US Tier 2 Bin 5 have lead to the deployment of Selective Catalytic Reduction (SCR) technology for heavy duty, and even passenger, diesel-powered vehicles.

ConstructionEquip

Construction Equipment HVAC Systems

Off-road vehicles like construction equipment require high levels of reliability and durability. Equipment downtime is a very costly event for machines that oftentimes must run 16 hours per day, or more, seven days per week.

geneva1943

Drive-by-Wire Control System

Drive-by-wire technology, such as used in the Novanta concept car shown here, replaces the heavy, cumbersome power-hungry traditional mechanical and hydraulic components with accurate, efficient electro-mechanical control systems.

Dual-Arm-Mk2-on-TALON

Dual-Arm Military Robot

Shown here mounted on the Talon mobile base is a dual-arm robotic manipulator system that is capable of lifting 110 lb (50 kg) and handling a myriad of field missions with human-like handling abilities.

FordFocusFCV 3

Fuel Cell Cooling System

Allied Motion has helped to develop advanced vehicle propulsion systems, such as Ford’s Focus FCV (Fuel Cell Vehicle) prototype shown here.

gps-tractor-steering

GPS-based Agricultural Vehicle Steering

One of the most successful tools available for modern precision farming is the GPS-based steering system.

bluetruck2

Heavy-Duty Truck HVAC Air Moving Systems

HVAC systems in “million-mile” trucks are required above all else to be reliable and quiet. The heart of these systems is motor used to power the blower or fan subsystem, which needs to be unquestionably reliable and provide very long service life.

Dragster_iStock_000004555683Small

High Performance Racing Fuel Pump

High performance vehicles such as drag racers require consistent high rates of fuel delivery to avoid mid-track “lay down” due to a lack of sufficient fuel. For example, an 800-HP engine needs more than 0.1 gallon every second of a run.

CBR600RR Croft

High Performance Racing Motorcycle Alternator

Minimizing total engine mass In racing motorcycles is of paramount importance because ever extra ounce reduces acceleration, and, hence, performance. Designers are therefore very keen to shed any unnecessary mass.

MilRobot_1_40559989_071605_008

IED Disposal Military Robot

Improvised Explosive Device (IED) disposal robots perform a critical role on today’s battlefield. These robots need to be extremely rugged and reliable yet lightweight and easy to maintain in the field.

JSOW_agm154

JSOW Missile Seeker Head

Allied Motion engineers designed a high resolution motor-encoder, limited-angle actuator to meet the extremely demanding requirements of modern smart standoff weapons such as the JSOW missile shown here.

AGV-in-warehouse-iStock-154048748-ThmbSq

Material Handling Carts & AGVs

Material movement in factories and warehouses is becoming easier and safer with the advent of robotic material handling carts.

CROWS_ 070912-F-4569G-002

Mobile Remotely Operated Weapons System

The CROWS (Common Remote Operated Weapons Station) weapons turret allows a gunner to remain protected inside his vehicle while accurately operating a computer-stabilized, laser-aimed weapon.

ConMediSys_HTB_Lg

Patient Transport Equipment

Developers of a new-concept patient transfer bed – a motorized gurney with a built-in transfer belt that enables a single caregiver to transfer a patient within a medical facility without having to physically lift the patient – sought Allied Motion’s assistance to motorize the 1400 lb. bed.

Blackhawk_iStock_000003619734Small

Pilot Cooling System Pump

Military helicopter pilots can be equipped with special flight suits that incorporate microclimate cooling. Cooling fluid is pumped through the suits by a special pump system driven by a brushless DC motor, keeping the pilot’s body temperature at near normal in harsh environmental conditions.

Stature 3GRXBASE_400_B

Power Wheelchair Drive

Medical mobility equipment such as power wheelchairs, scooters, stair lifts, and elevators require dependable, quiet DC or brushless DC motors and gear motors for reliable, long life operation.

DaneTech_QKM3_9633_052606E-2

Powered Pusher/Puller Cart Assistant

Small, powered pusher and tugger vehicles are being used increasingly in commercial and industrial settings for their productivity gains, and the worker safety and injury reduction they afford.

Savaria Curved_1

Powered Stair Lift

All powered medical access and mobility equipment like the stair lift shown here is expected to operate quietly and reliably over many years of numerous daily cycles.

RV 1

Recreational Vehicle Convenience Systems

Modern RVs and personal luxury buses pack a lot of “at-home” conveniences into a small space through the use of electrically-powered systems like slide-outs, bed stows and lifts, jacking and awning systems, and heating/cooling and water pumping systems.

ISS

Space Station Experiment Module

Allied Motion engineered a large custom 560 mm (22 in.) diameter torque motor with encoder for the International Space Station. The motor was designed to power a 2.5 m (8.2 ft) diameter centrifuge rotor capable of providing artificial gravity levels ranging from 0.001 to 2 g.

Train Door

Train Door Operators

Allied Motion is a leading supplier of actuator motors and gear motors to tough applications such as door operators in the light rail and passenger train market.

Detail of Yachts and Reflection

Vessel Engine Oil Change System Pump

Changing crankcase oil for inboard mounted marine power plants, whether in a large yacht or smaller pleasure boats, is a difficult, dirty job.

predator-firing-missile4

UAV Gimbal Motion Control

Advanced micro-gimbals with high performance inertial stabilization technology are found on both land-based and aerial platforms such as military UAVs like the Predator.

High speed power boat with hydraulic steering-assist

Watercraft Hydraulic Power Steering

Manual steering of power boats becomes difficult the larger and more powerful the boat, especially those outfitted with multiple engines.

Harmar-wheelchair-lift KO 300 900

Wheelchair & Scooter Auto Lift

Transporting and handling medical equipment is made easier using specialized equipment designed for the purpose such as the wheelchair/scooter lift shown here.
